WiFi

WiFi 7

Sockel

AM5

Chipset

AMD X870E

M.2-platser

7

Ethernet

10 Gigabit

Max minne

256 GB

PCIe-platser

2x PCIe 5.0 x16, 2x PCIe 4.0 x16

SATA-portar

4

Ljudkodek

SupremeFX ALC4082

Dimensioner

305 × 277mm

Formfaktor

EATX

Minnestyp

DDR5

Minnesplatser

4

Displayutgångar

USB4 x2

Max minneshastighet

8600 MHz

Övriga specifikationer

USB

Rear USB (Total 14 ports) 2 x USB4 (40Gbps) ports (2 x USB Type-C) 12 x USB 10Gbps ports (8 x Type-A + 4 x USB Type-C) Front USB (Total 12 ports) 1 x USB 20Gbps connector (supports USB Type-C with up to 60W PD/QC4+)* 1 x USB 20Gbps connector (supports USB Type-C) 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports 3 x USB 2.0 headers support 6 additional USB 2.0 ports USB Type-C power delivery output: max. 5V/3A *USB Type-C power delivery output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A

BIOS

2 x 512 Mb Flash ROM, UEFI AMI BIOS

Accessories

Cables 1 x 1-to-4 ARGB splitter cable 1 x 1-to-2 ARGB splitter cable 2 x 1-to-3 fan splitter cable 2 x ROG weave SATA 6G cable packages ROG Hyper M.2 Card with Heatsink 1 x ROG Hyper M.2 with heatsink 1 x M.2 pad package for ROG Hyper M.2 Card 2 x Thermal pad for ROG Hyper M.2 Card ROG Q-DIMM.2 with Heatsink 1 x ROG DIMM.2 with heatsink 1 x M.2 pad package for ROG Q-DIMM.2 2 x Thermal pad for ROG Q-DIMM.2 Additional Cooling Kit 1 x Thermal pad for M.2 22110 1 x ROG Memory Q-Fan Miscellaneous 1 x ASUS WiFi Q-Antenna 1 x Q-connector 1 x ROG logo plate sticker 1 x ROG stickers 1 x ROG VIP card 1 x M.2 Q-Slide package 7 x M.2 backplate rubber packages 1 x ROG Bottle Opener Documentation 1 x Quick start guide

RAID Support

AMD RAIDXpert2 Technology Ryzen 9000 & 8000 & 7000 Series Processors: RAID 0/1/5/10* *SATA ports from ASM1162 cannot support RAID

Manageability

WOL by PME

News & Updates

Socket AM5

Operating System

Windows 11

Special Features

Extreme OC Kit - FlexKey button - LN2 Mode - ProbeIt - ReTry button - Safe boot button - Start button Extreme Engine Digi+ - 10K Black Metallic Capacitors - MicroFine Alloy Choke ASUS Q-Design - M.2 Q-Latch - M.2 Q-Release - M.2 Q-Slide - PCIe Q-Release Switch (with PCIe SafeSlot) - Q-Antenna - Q-Code - Q-Connector - Q-Dashboard - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-DIMM.2 ASUS Thermal Solution - M.2 heatsink backplate - M.2 heatsink - Metal backplate - VRM heatsink design - 3D VC M.2 Heatsink - ROG Memory Q-Fan ASUS EZ DIY - Backplate - BIOS FlashBack button - Clear CMOS button - CPU Socket lever protector - ProCool II - Pre-mounted I/O shield - SafeSlot - SafeDIMM Aura Sync - Addressable Gen 2 headers Dual BIOS Full Color 5" LCD Display Front Panel USB 20Gbps with Quick Charge 4+ Support - Support: up to 60W fast charging and USB Wattage Watcher* - Output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A - Compatible with PD3.0 and PPS * To support 60W, please install the power cable to the 8-pin PCIe power connector or else only 27W will be supported.

Software Features

ROG Exclusive Software - ROG CPU-Z - Dolby Atmos - LCD Display - Internet Security (1-year full version) ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Fan Xpert 4 (with AI Cooling II) - GameFirst - WiFi Q-Antenna - MLO Wizard ASUS DriverHub - ASUS MB Manager - ASUS AI Advisor - AIDA64 Extreme (1 year full version) - HWiNFO - Turbo Vcore - ASUS GlideX - USB Wattage Watcher WinRAR (40 Days Free Trial) Adobe Creative Cloud (Free Trial) UEFI BIOS Integrated WiFi Driver Support AI Overclocking Guide AI Cache Boost ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode - ASUS MyHotkey FlexKey * For more software features, please visit the asus support site or refer to www.asus.com/support for additional information. ** For detailed information on the supported models and restricted regions for this redemption offer, please refer to https://www.asus.com/content/asus-offers-adobe-creative-cloud/.

Back Panel I/O Ports

2 x USB4 (40Gbps) ports (2 x USB Type-C) 12 x USB 10Gbps ports (8 x Type-A + 4 x USB Type-C) 1 x Wi-Fi Module 2 x Realtek 10Gb Ethernet ports 2 x LED-illuminated audio jacks 1 x Optical S/PDIF out port 1 x BIOS FlashBack button 1 x Clear CMOS button

Internal I/O Connectors

Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 2 x 4-pin Chassis Fan headers 2 x 4-pin Radiator Fan headers 2 x W_PUMP+ headers 1 x AIO Q-Connector 1 x Extra Flow Fan header Power related 1 x 24-pin Main Power connector 2 x 8-pin +12V CPU Power connector 1 x 8-pin PCIe Power connector Storage related 3 x M.2 slots (Key M) 1 x DIMM.2 slot supports 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 2 x USB 20Gbps connector (supports USB Type-C) 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports 3 x USB 2.0 headers support 6 additional USB 2.0 ports Miscellaneous 1 x 6-pin ARGB Gen 2 header to support 2 x ARGB Gen 2 headers 2 x Addressable Gen 2 header 1 x Alteration PCIe mode switch 2 x BCLK button 1 x BIOS Switch 1 x FlexKey button 1 x Front Panel Audio header (F_AUDIO) 1 x LN2 Mode jumper 12 x ProbeIt Measurement Points 1 x ReTry button 1 x RSVD header 1 x Safe Boot button 1 x Start button 1 x 10-1 pin System Panel header 1 x Thermal Sensor header
