Djup

432 mm

Bredd

305 mm

Höjd

410 mm

Volym

54 L

Vikt

10 kg

Front I/O

1x USB-C, 2x USB-A, Audio: Mic + Audio

Material

Glass, Steel

Dimensioner

432 × 305 × 410mm

Formfaktor

ATX / Micro-ATX / Mini-ITX

2.5"-fack

2

3.5"-fack

1

Medföljande fläktar

rear: 1x Light Wings LX 120mm PWM White, side: 3x Light Wings LX Reverse 120mm PWM White

Max GPU-längd

400 mm

Max PSU-längd

200 mm

Sidopanel

Steel

Expansionsplatser

7

Max kylarhöjd

185 mm

Radiatorstöd (topp)

120mm / 240mm / 280mm / 360mm

Övriga specifikationer

Top

-

RoHS

✓

Side

1

WEEE

✓

Front

-

Reach

-

Bottom

1

Stands

ABS

Triman

✓

EAN code

4260052193891

LED type

-

Approvals

CE / RoHS

Connector

4-pin PWM

RRP (€)

154.90

Rear (mm)

120

Screw box

-

Side (mm)

120 / 240

PSU shroud

-

VGA holder

-

Volume (l)

49,6

Bottom (mm)

-

LEDs (pcs.)

-

ODD Bracket

-

Color option

White

Maximum fans

10

Article number

BGW86

Fan controller

1x 12 Ports

Airflow channel

-

Input power (W)

3.8

PSU form factor

ATX PS/2

5.25 bays (pcs.)

-

LED illumination

✓

Mesh Front Panel

-

Warranty (Years)

3

Cable ties (pcs.)

5

Input current (A)

0.32

LED strips (pcs.)

-

Lifespan (h / 25°C)

60,000

Voltage range (V DC)

5 - 13.2

Pieces per packaging unit

1

Top panel insulation mats

-

Gross weight, package (kg)

14.6

SSD bracket for PSU shroud

-

Side panel insulation mats

-

Additional standoffs (pcs.)

1

Front panel insulation mats

-

Anti-vibration decoupled HDD

✓

Anti-vibration decoupled PSU

✓

Anti-vibration decoupled fan

✓

Dimensions (L x W x H), (mm)

120 x 120 x 25

Screw set (Drives/Motherboard)

✓

VGA holder for inverted layout

✓

Fan speed at 100% PWM / 12V (rpm)

1600 | 1500

Dimensions, package (L x W x H), (mm)

493 x 388 x 515

Noise level at 100% PWM / 12V (dB(A))

25.5

Airflow at 100% PWM / 12V (CFM / m3/h)

51.5 / 87.5

International hotline / free of charge

✓ / DE, FR

Qi charger / Quick Charging Option (W)

-

Air Pressure at 100% PWM / 12V (mm H2O)

1.34

Case size incl. stands (L x W x H), (mm)

432 x 305 x 436

Anti-vibration decoupled motherboard-tray

-

Fan / Radiator bracket for multi mounting panel

-

LEDs synchronizable with controller/motherboard

✓

Maximum PCIe slots with vertical graphics card (pcs.)

4
