Djup

450 mm

Bredd

305 mm

Höjd

435 mm

Volym

59.7 L

Vikt

12.1 kg

Front I/O

1x USB-C, 2x USB-A, Audio: Mic + Audio

Material

Steel, Glass

Dimensioner

450 × 305 × 435mm

Formfaktor

ATX / Micro-ATX / Mini-ITX

2.5"-fack

4

3.5"-fack

2

Max GPU-längd

400 mm

Max PSU-längd

200 mm

Sidopanel

Glass

Expansionsplatser

7

Max kylarhöjd

170 mm

Radiatorstöd (topp)

120mm / 240mm / 360mm

Övriga specifikationer

Top

-

RoHS

✓

Side

1

WEEE

✓

Front

-

Reach

-

Bottom

-

Stands

ABS

Triman

✓

EAN code

4260052191729

LED type

ARGB - 5V

Approvals

CE, UKCA

Connector

-

RRP (€)

159.90

Rear (mm)

120

Screw box

-

Side (mm)

120 / 240

PSU shroud

-

VGA holder

✓

Volume (l)

59.7

Bottom (mm)

120 / 240 / 360

LEDs (pcs.)

77

ODD Bracket

-

Color option

White

Maximum fans

10

Article number

BGW66

Fan controller

-

Airflow channel

-

Input power (W)

-

PSU form factor

ATX PS/2

5.25 bays (pcs.)

-

LED illumination

✓

Mesh Front Panel

-

Warranty (Years)

3

Cable ties (pcs.)

12

Input current (A)

-

LED strips (pcs.)

-

Lifespan (h / 25°C)

-

Voltage range (V DC)

-

Pieces per packaging unit

1

Top panel insulation mats

-

Gross weight, package (kg)

14.0

SSD bracket for PSU shroud

-

Side panel insulation mats

-

Additional standoffs (pcs.)

1

Front panel insulation mats

-

Anti-vibration decoupled HDD

✓

Anti-vibration decoupled PSU

✓

Anti-vibration decoupled fan

✓

Dimensions (L x W x H), (mm)

-

Screw set (Drives/Motherboard)

✓

VGA holder for inverted layout

✓

Fan speed at 100% PWM / 12V (rpm)

-

Dimensions, package (L x W x H), (mm)

523 x 390 x 554

Noise level at 100% PWM / 12V (dB(A))

-

Airflow at 100% PWM / 12V (CFM / m3/h)

-

International hotline / free of charge

✓ / DE, FR

Qi charger / Quick Charging Option (W)

-

Air Pressure at 100% PWM / 12V (mm H2O)

-

Case size incl. stands (L x W x H), (mm)

450 x 305 x 455

Anti-vibration decoupled motherboard-tray

-

Fan / Radiator bracket for multi mounting panel

-

LEDs synchronizable with controller/motherboard

✓

Maximum PCIe slots with vertical graphics card (pcs.)

4
