Vikt

7.9 kg

Front I/O

2x USB Type-A 5 Gbps, 1x USB Type-C 20 Gbps, 1x Audio Jack, 1x Microphone Jack

Material

Steel, Tempered Glass

Dimensioner

447 × 215 × 469 mm

Formfaktor

ATX / mATX / Mini-ITX

Max 120 mm-fläktar

6

Max 140 mm-fläktar

4

2.5"-fack

2

Medföljande fläktar

front: 3 x Momentum 12

Max GPU-längd

360 mm

Max PSU-längd

255 mm

Sidopanel

Tempered Glass

Expansionsplatser

7

Max kylarhöjd

170 mm

Radiatorstöd (topp)

240mm

Radiatorstöd (front)

360mm

Övriga specifikationer

EAN

7340172711179

UPC

843276111175

Top fan

2 x 120 mm or 2 x 140 mm

Rear fan

1 x 120 mm

Warranty

2 Years

Front fan

3 x 120 mm or 2 x 140 mm (3 x Momentum 12 Included)

Other EAN

7340172711179

Other UPC

843276111175

Bottom fan

-

Net weight

7.9 kg

Thumbscrews

PCIe slots

Dust filters

Front (nylon), PSU (nylon), top (steel)

Gross weight

9.5 kg

Product Code

FD-C-NOR1C-05

Top radiator

Up to 240 mm (See manual for RAM clearance)

Rear radiator

1 x 120 mm

Front radiator

Up to 360 mm

GPU max length

355 mm with front fans mounted, 300 mm with 360 mm front radiator mounted

Other Warranty

2 Years

PSU max length

1 HDD Tray: 255 mm max 2 HDD Tray: 155 mm max

Bottom radiator

-

Expansion slots

7

Front interface

2 x USB Type-A 5 Gbps, 1x USB Type-C 20 Gbps, 1 x Audio Jack, 1 x Microphone Jack

Left side panel

Tempered Glass

Package contents

PC Case, Accessory Box, User Manual

Right side panel

Steel

Tool-less access

Top, left, right, and front panels

Total fan mounts

6 x 120 mm or 4 x 140 mm

Power supply type

ATX

Side Bracket Fans

-

Other Product Code

FD-C-NOR1C-05

Cable routing space

30 mm

Captive thumbscrews

HDD brackets, SSD bracket, Side Panels, PSU Bracket

5.25” drive mounts

-

CPU cooler max height

170 mm

Cable routing grommets

Yes

Other Package contents

PC Case, Accessory Box, User Manual

Specifications Top fan

2 x 120 mm or 2 x 140 mm

Case dimensions (LxWxH)

447 x 215 x 469 mm

Dimensions Gross weight

9.5 kg

Specifications Rear fan

1 x 120 mm

Cable management features

Hook-and-loop straps

Motherboard compatibility

ATX / mATX / Mini-ITX

Specifications Bottom fan

-

Package dimensions (LxWxH)

565 x 326 x 553 mm

Specifications Thumbscrews

PCIe slots

Compatibility Rear radiator

1 x 120 mm

Dedicated 2.5" drive mounts

2

Dedicated 3.5" drive mounts

-

Specifications Dust filters

Front (nylon), PSU (nylon), top (steel)

Compatibility Bottom radiator

-

Compatibility Power supply type

ATX

Specifications Tool-less access

Top, left, right, and front panels

Combined 3.5/2.5” drive mounts

2 (2 included)

Specifications Side Bracket Fans

-

Specifications Cable routing space

30 mm

Specifications Captive thumbscrews

HDD brackets, SSD bracket, Side Panels, PSU Bracket

Specifications 5.25” drive mounts

-

Dimensions Package dimensions (LxWxH)

565 x 326 x 553 mm

Specifications Cable routing grommets

Yes

Specifications Cable management features

Hook-and-loop straps

Specifications Dedicated 3.5" drive mounts

-

Specifications Combined 3.5/2.5” drive mounts

2 (2 included)
