WiFi

WiFi 7

Sockel

LGA 4677

Chipset

Intel W790 Express Chipset

M.2-platser

4

Ethernet

10 Gigabit

Max minne

256 GB

PCIe-platser

CPU: - 5 x PCI Express x16 slots, supporting PCIe 5.0 and running at x16 * The PCIEX16_4 and PCIEX16_5 slots become unavailable when an Intel Xeon W-2500/W-2400 series processor is used. * The PCI Express x16 slots support only graphics cards or NVMe SSDs. For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16_1 slot.

SATA-portar

8

Dimensioner

305 × 330mm

Formfaktor

EATX

Minnestyp

DDR5

Minnesplatser

8

Max minneshastighet

4800 MHz

Övriga specifikationer

USB

Chipset+Intel Thunderbolt 4 Controller: - 2 x USB4 USB Type-C ports on the back panel Chipset: - 1 x USB Type-C port with USB 3.2 Gen 2x2 support, available through the internal USB header - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel - 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) Chipset+USB 2.0 Hub: - 4 x USB 2.0/1.1 ports available through the internal USB headers

BIOS

1 x 512 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

I/O kontroller

iTE I/O Controller Chip

Operativsystem

Support for Windows 11 64-bit

Unika funktioner

Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup

Hårdvaru visning

Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Fan fail warning Fan speed control * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

Bundlad programvara

Norton Internet Security (OEM version) LAN bandwidth management software

Interna I/O kontakter

1 x 24-pin ATX main power connector 4 x 8-pin ATX 12V power connectors 1 x PCIe power connector 1 x CPU fan header 1 x CPU fan/water cooling pump header 6 x system fan headers 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 6 x M.2 Socket 3 connectors 8 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 2x2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) 1 x power button 1 x reset button 1 x Q-Flash Plus button 1 x speaker header 1 x reset jumper 2 x temperature sensor headers 1 x Clear CMOS jumper 1 x Intel VROC Upgrade Key header

Kontakter på baksidan

2 x DisplayPort In ports 2 x Thunderbolt 4 connectors (USB4 USB Type-C ports) 2 x antenna connectors (2T2R) 2 x USB 3.2 Gen 2 Type-A ports (red) 4 x USB 3.2 Gen 1 ports 2 x RJ-45 ports 1 x optical S/PDIF Out connector 2 x audio jacks
