1x DVI-D port, support a maximum resolution of 1920x1200 @60Hz 1; 1x HDMI 2.0b port, supports a maximum resolution of 4096x2160 @30Hz, 2560x1600 @60Hz 1/2; Maximum shared memory of 16 GB; Available only on processors featuring integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Max minneshastighet
2667 MHz
Övriga specifikationer
HDMI
1
RAID
0/1/10
DVI-D
1
Socket
AM4
Jumpers
1x Clear CMOS jumper
SATAIII
6
M.2 Slot
1
PCI-E x1
4
Software
MSI Center; CPU-Z MSI GAMING; Google Chrome, Google Toolbar, Google Drive; Norton Internet Security Solution
Keyboard / Mouse; USB 3.2 Gen 1 5Gbps Type-A; LAN; Audio Connectors; Flash BIOS Button; USB 2.0; DVI-D; HDMI; USB 3.2 Gen 2 10Gbps Type-A
Hardware Monitor
CPU/ System/ Chipset temperature detection; CPU/ System/ Pump fan speed detection; CPU/ System/ Pump fan speed control
Power Connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector
System Connectors
1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x TPM module connector; 1x Serial port connector; 1x Parallel port connector
Audio ports (Rear)
Realtek ALC897 Codec
USB 2.0 ports (Rear)
2
USB 3.2 ports (Rear)
2(Gen 2, Type A), 2(Gen 1, Type A)
USB 2.0 ports (Front)
4
USB 3.2 ports (Front)
2(Gen 1, Type A)
Internal USB Connectors
1x USB 3.2 Gen 1 5Gbps connector (From B550 chipset) Supports additional 2 USB 3.2 Gen 1 5Gbps ports; Supports additional 2 USB 3.2 Gen 1 5Gbps ports; 2x USB 2.0 connectors (From B550 chipset) Supports additional 4 USB 2.0 ports; Supports additional 4 USB 2.0 ports
