- USB
- 3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector); 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors); 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
- VGA
- 1
- HDMI
- 1
- RAID
- 0/1/10
- Socket
- AMD Socket AM4
- DirectX
- 12
- SATAIII
- 4
- M.2 Slot
- 2
- MOUNTING
- 8 mounting holes
- PCI-E x1
- 2
- PCI-E Gen
- Gen4 / Gen3
- PCI-E x16
- 1
- DIMM Slots
- 4
- Dimensions
- Micro-ATX Form Factor; 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
- Box content
- MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
- CPU Support
- Support for Windows 10 64-bit
- DisplayPort
- 1
- Form Factor
- MATX
- TPM (header)
- 1
- Expansion Slot
- 1x PCIe 4.0/ 3.0 x16 slot (PCI_E1) 1; 2x PCIe 3.0 x1 slots; The supported specification depends on installed processor.
- Memory Channel
- Dual
- Max Memory (GB)
- 128
- Back panel ports
- VGA; USB 3.2 Gen 1 5Gbps Type-A; Keyboard / Mouse; LAN; Flash BIOS Button; DisplayPort; HDMI; USB 2.0; USB 3.2 Gen 1 5Gbps Type-A; Wi-Fi Antenna connectors; 3x Audio jacks
- WiFi & Bluetooth
- WiFi-AC, Bluetooth 4.2
- Audio ports (Rear)
- Realtek ALC892/ALC897 Codec
- Internal connectors
- 1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 4x SATA 6Gb/s connectors; 2x M.2 slots (M-Key); 1x USB 3.2 Gen 1 5Gbps Type-C port; 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 3x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Serial port connector; 1x Chassis Intrusion connector; 2x 4-pin RGB LED connectors; 2x 3-pin RAINBOW LED connectors; 1xTPM module connector; 1x Clear CMOS jumper
- Serial ports(Front)
- 1
- USB 2.0 ports (Rear)
- 2
- USB 3.2 ports (Rear)
- 4(Gen 1, Type A)
- USB 2.0 ports (Front)
- 4
- USB 3.2 ports (Front)
- 1(Gen 1, Type C), 2(Gen 1, Type A)
