1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz 1 2 Support HDCP 1.4 & 2.3; 1x DisplayPort 1.4 port, supports a maximum resolution of 4096x2160 @60Hz 1; Maximum shared memory of 16GB; Available for the processor with integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Max minneshastighet
1866 MHz
Övriga specifikationer
USB
2x USB 3.2 Gen 1 5Gbps ports (2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector); 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors); 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
M-ATX Form Factor; 9.6 in. x 8.3 in. (24.4 cm x 21 cm)
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 10 64-bit
DisplayPort
1
Form Factor
M-ATX
TPM (header)
1
Expansion Slot
1x PCIe 3.0 x16 slot (From AMD processor) Supports x16 speed with Ryzen 5000, 5000G, 4000G and 3000 processors Supports x8 speed with Ryzen 3000G processors Supports x4 speed with AMD Athlon with Radeon Graphics processors; Supports x16 speed with Ryzen 5000, 5000G, 4000G and 3000 processors; Supports x8 speed with Ryzen 3000G processors; Supports x4 speed with AMD Athlon with Radeon Graphics processors; 2x PCIe 3.0x1 slots
Memory Channel
Dual
Max Memory (GB)
64
Back panel ports
Keyboard / Mouse; LAN port; Wi-Fi Antenna connectors; Audio Connectors; HDMI; DisplayPort; USB 2.0 Ports; USB 3.2 Gen 1 5Gbps Type-A; USB 3.2 Gen 1 5Gbps Type-A
Audio ports (Rear)
Realtek ALC892/ALC897 Codec
Internal connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 4x SATA 6Gb/s connectors; 1x Serial port connector; 1x M.2 slot (M-Key); 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin system fan connector; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x 4-pin RGB LED connector; 1x 3-pin RAINBOW LED connector; 1x TPM module connector; 1x Clear CMOS jumper
