1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz 1 2 Support HDCP 1.4 & 2.3; 1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz 1; Maximum shared memory of 16 GB; Available for the processor with integrated graphics.; Graphics specifications may vary depending on the CPU installed.
Max minneshastighet
1866 MHz
Övriga specifikationer
USB
3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector); 8x USB 2.0 ports (4 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors); 2x USB 3.2 Gen 2 10Gbps ports (1 Type-C port and 1 Type-A port on the back panel); 2x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
Recensioner
Laddar recensioner…
HDMI
1
RAID
0/1/10
Socket
AM4
DirectX
12
SATAIII
6
M.2 Slot
2
Mounting
9 mounting holes
PCI-E x1
2
CrossFire
Y
Multi-GPU
Supports 2-Way AMD CrossFire Technology
PCI-E x16
2
DIMM Slots
4
Dimensions
ATX Form Factor; 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Box content
MSI does not guarantee the risks or damages caused by changing the cover.; These pictures are for reference only and may vary without notice.
CPU Support
Support for Windows 10 64-bit
DisplayPort
1
Form Factor
ATX
LED Features
1x EZ LED Control switch; 4x EZ Debug LED
TPM (header)
1
I/O Controller
NUVOTON NCT6687-R Controller Chip
Memory Channel
Dual
Expansion Slots
1x PCIe 4.0/ 3.0 x16 slot (PCI_E1) 1; 1x PCIe 3.0 x16 slot (PCI_E3), supports x4 speed 2; 2x PCIe 3.0 x1 slots; The supported specification depends on installed processor.; When installing PCIe SSD in M.2_2, PCI_E3 slot will be unavailable.
Max Memory (GB)
128
Back panel ports
PS/2 Combo Port; DisplayPort; LAN Port; USB 3.2 Gen 2 10Gbps (Type-A); HD Audio Connectors; Flash BIOS Button; USB 2.0; HDMI; USB 2.0; USB 3.2 Gen 1 5Gbps (Type-A); USB 3.2 Gen 2 10Gbps (Type-C); Optical S/PDIF OUT
Hardware Monitor
CPU/ System/ Chipset temperature detection; CPU/ System/ Pump fan speed detection; CPU/ System/ Pump fan speed control
Audio ports (Rear)
Realtek ALC892/ALC897 Codec
Internal connectors
1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 6x SATA 6Gb/s connectors; 2x M.2 slots (M-Key); 1x USB 3.2 Gen 1 5Gbps Type-C port; 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 6x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 1x 4-pin RGB LED connector; 2x 3-pin RAINBOW LED connectors; 1xTPM module connector; 1x Clear CMOS jumper
USB 2.0 ports (Rear)
4
USB 3.2 ports (Rear)
1(Gen 2, Type C), 1(Gen 2, Type A), 2(Gen 1, Type A)
