- Panels Top
- Steel (mesh)
- Panels Bottom
- Nylon dust filter
- Fan Support Top
- 3 × 120 mm
- Fan Support Rear
- 1 × 120 mm
- Panels Left Side
- Tempered glass
- Product Info EAN
- 5056547209364 (White) / 5056547209357 (Black)
- Product Info UPC
- 810074846905 (White) / 810074846899 (Black)
- Dimensions Volume
- 55 L
- Fan Support Bottom
- 3 × 120 mm
- Product Info Warranty
- 2 years
- Radiator Support Rear
- 120 mm
- Front I/O Headset Jack
- 1
- Fan Support Front-Right
- 3 × 120 mm
- General Specs Materials
- Steel, tempered glass
- Control Hub Fan Channels
- 2 x NZXT 8-pin (PWM only) / 1 x 4-pin PWM (DC+PWM control)
- Control Hub RGB Channels
- 2 x NZXT 8-pin / 1 x NZXT RGB
- Cooling Support Rear Fan
- 1 x 120 mm
- Cooling Support Top Fans
- 3 x 120 mm
- Front I/O USB 3.2 Type-A
- 2
- Included Fan Specs Model
- F360 RGB Reverse / F120 RGB
- Included Fan Specs Speed
- 2,200 ± 220 RPM / 2,400 ± 240 RPM
- General Power Supply Type
- ATX
- Product Info Model Number
- CC-H62FW-P1 (White) / CC-H62FB-P1 (Black)
- Fan Specs (F120 RGB) Noise
- 33.05 dBA
- Fan Specs (F120 RGB) Speed
- 2,400 ± 240 RPM
- Included Fan Specs Airflow
- 62.14 CFM / 70.67 CFM
- Control Hub Max LED Support
- Each NZXT 8-pin channel supports a maximum of 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to 5 NZXT devices.
- Cooling Support Bottom Fans
- 3 x 120 mm
- General Motherboard Support
- ATX, Micro-ATX, Mini-ITX
- Included Fan Specs Quantity
- 2 / 1
- Cooling Support Top Radiator
- Up to 360 mm (Up to 400 mm)
- Fan Specs (F120 RGB) Airflow
- 70.67 CFM
- General Specs Enclosure Type
- Dual-chamber ATX case
- Clearance Cable Routing Space
- Up to 90 mm (3.5 in)
- Cooling Support Rear Radiator
- Up to 120 mm
- Fan Specs (F120 RGB) Quantity
- 1
- Front I/O USB 3.2 Gen1 Type-A
- 2
- Included Fan Specs Noise Level
- 34.39 dBA / 33.05 dBA
- Control Hub System Requirements
- USB 2.0 Internal Header / SATA Power
- Front I/O USB 3.2 Gen2x2 Type-C
- 1
- General Specs Power Supply Type
- ATX
- Panels Front-Right / Right Side
- Steel (mesh)
- Cooling Support Front-Right Fans
- 3 x 120 mm
- Front I/O USB 3.2 Gen 2x2 Type-C
- 1
- Included Fan Specs Fan Connector
- 8-pin (4-pin PWM and NZXT RGB combo) / 4-pin
- Dimensions Dimensions (H x W x D)
- 448 x 292 x 420 mm (17.6 x 11.5 x 16.5 in)
- Cable Management Included Zip Ties
- Yes
- Expansion & Drives 2.5" Drive Bays
- 2
- Expansion & Drives 3.5" Drive Bays
- 1
- Expansion & Drives Expansion Slots
- 7
- Fan Specs (F120 RGB) Fan Connector
- 4-pin
- Fan Specs (F360 RGB Reverse) Noise
- 34.39 dBA per fan
- Fan Specs (F360 RGB Reverse) Speed
- 2,200 ± 220 RPM
- Included Fan Specs Static Pressure
- 2.7 mmH₂O / 3.7 mmH₂O
- Clearance Front-Right Fan Thickness
- Up to 30 mm (without limiting GPU length)
- Control Hub Lite Specs Fan Channels
- 2 × NZXT 8-pin (PWM only) / 1 × 4-pin PWM (DC+PWM control)
- Control Hub Lite Specs RGB Channels
- 2 × NZXT 8-pin / 1 × NZXT RGB
- Cable Management Fixed Velcro Straps
- Yes
- Fan Specs (F120 RGB) Static Pressure
- 3.7 mmH₂O
- Fan Specs (F360 RGB Reverse) Airflow
- 62.14 CFM per fan
- Fan Specs (F360 RGB Reverse) Quantity
- 2
- Clearance Top Radiator + Fan Thickness
- Up to 67 mm (2.6 in)
- Control Hub Lite Specs Max LED Support
- Each NZXT 8-pin channel supports a maximum of 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to 5 NZXT devices.
- General Specs Motherboard Compatibility
- ATX / Micro-ATX / Mini-ITX
- General Back-Connect Motherboard Support
- Yes (ATX)
- Control Hub Lite Specs System Requirements
- USB 2.0 Internal Header / SATA Power
- Fan Specs (F360 RGB Reverse) Fan Connector
- 8-pin (4-pin PWM and NZXT RGB combo)
- Fan Specs (F360 RGB Reverse) Static Pressure
- 2.7 mmH₂O per fan
- General Specs Rear-Connecting Motherboard Support
- Yes (ATX)
