Vikt

13.4 kg

Front I/O

2x USB 3.2 Type-A, 1x USB 3.2 Gen2x2 Type-C, 1x Headset Jack

Chassityp

Mid-tower

Material

SGCC steel, clear tempered glass (white), tinted tempered glass (black)

Dimensioner

315 × 481 × 506mm

Formfaktor

EATX

2.5"-fack

6

3.5"-fack

2

Medföljande fläktar

Front-Right: 1 x F420 RGB Core; Bottom: 1 x F420 RGB Core; Rear: 1 x 120 mm (1 x F120 RGB (CV) included)

Max GPU-längd

459 mm

Max PSU-längd

200 mm

Sidopanel

Tempered Glass

Expansionsplatser

7

Max kylarhöjd

165 mm

Radiatorstöd (topp)

Up to 420 mm

Radiatorstöd (front)

Up to 420 mm

Övriga specifikationer

Fan Support Top

3 x 120 mm / 3 x 140 mm

Product Info EAN

5056547207674 5056547207681 5056547208886 5056547208893

Product Info UPC

810074847889 810074847896 815671019530 815671019547

Dimensions Volume

76.7 L

Warranty Warranty

2 years

Radiator Support Rear

Up to 120 mm

Radiator Support Bottom

Up to 360 mm

Expansion Slots Vertical

0

Product Info Model Number

CM-H92FW-P1 CM-H92FB-P1 CM-H92FW-P2 CM-H92FB-P2

Control Hub Specs Fan Channels

3 x NZXT 8-pin (PWM only) / 1 x NZXT 8-pin (DC+PWM control) / 1 x 4-pin PWM (DC+PWM control)

Control Hub Specs RGB Channels

4 x NZXT 8-pin / 1 x NZXT RGB

Fan Specs - F420 RGB Core Model

F420 RGB Core

Fan Specs - F420 RGB Core Noise

34.5 dBA

Fan Specs - F420 RGB Core Speed

2,000 ± 200 RPM

Control Hub Specs Max LED Support

Each NZXT 8-pin channel supports a maximum of 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to NZXT 5 devices.

Fan Specs - F420 RGB Core Airflow

98.61 CFM

Fan Specs - F120 RGB Core (CV) Model

F120 RGB Core (CV)

Fan Specs - F120 RGB Core (CV) Noise

26.1 dBA

Fan Specs - F120 RGB Core (CV) Speed

1,300 ± 130 RPM

Control Hub Specs System Requirements

USB 2.0 Internal Header 8-pin PCIe Power

Clearance Top Radiator & Fan Thickness

Up to 80 mm (360 mm) Up to 62 mm (420 mm)

Fan Specs - F120 RGB Core (CV) Airflow

55.17 CFM

Fan Specs - F420 RGB Core Fan Connector

8-pin

Fan Specs - F420 RGB Core Static Pressure

3.2 mmH2O

Fan Specs - F120 RGB Core (CV) Fan Connector

3-pin

Fan Specs - F120 RGB Core (CV) Static Pressure

1.27 mmH2O

General Rear-Connecting Motherboard Support (BTF, Project Zero)

Yes (ATX)
