Vikt

12.46 kg

Front I/O

2x USB 3.2 Type-A, 1x USB 3.2 Gen2x2 Type-C, 1x Headset Jack

Chassityp

Mid-tower

Material

SGCC steel, clear tempered glass (white), tinted tempered glass (black)

Dimensioner

315 × 481 × 506mm

Formfaktor

EATX

2.5"-fack

6

3.5"-fack

2

Medföljande fläktar

Front-Right: 3 x 120 mm / 3 x 140 mm (3 x F140Q (CV) included); Rear: 1 x 120 mm (1 x F120Q (CV) included)

Max GPU-längd

459 mm

Max PSU-längd

200 mm

Sidopanel

Tempered Glass

Expansionsplatser

7

Max kylarhöjd

165 mm

Radiatorstöd (topp)

Up to 420 mm

Radiatorstöd (front)

Up to 420 mm

Övriga specifikationer

Fan Support Top

3 x 120 mm / 3 x 140 mm

Product Info EAN

5056547207636 5056547207643 5056547208848 5056547208855

Product Info UPC

810074847841 810074847858 815671019493 815671019509

Dimensions Volume

76.7 L

Warranty Warranty

2 years

Fan Support Bottom

3 x 120 mm / 3 x 140 mm

Radiator Support Rear

Up to 120 mm

Radiator Support Bottom

Up to 360 mm

Expansion Slots Vertical

0

Product Info Model Number

CM-H92FW-01 CM-H92FB-01 CM-H92FW-02 CM-H92FB-02

Fan Specs - F120Q (CV) Model

F120Q (CV)

Fan Specs - F120Q (CV) Noise

24.1 dBA

Fan Specs - F120Q (CV) Speed

1,350 ± 150 RPM

Fan Specs - F140Q (CV) Model

F140Q (CV)

Fan Specs - F140Q (CV) Noise

22.9 dBA

Fan Specs - F140Q (CV) Speed

1,350 ± 150 RPM

Fan Specs - F120Q (CV) Airflow

60.2 CFM

Fan Specs - F140Q (CV) Airflow

100.25 CFM

Fan Specs - F120Q (CV) Fan Connector

3-pin

Fan Specs - F140Q (CV) Fan Connector

3-pin

Clearance Top Radiator & Fan Thickness

Up to 80 mm (360 mm) Up to 62 mm (420 mm)

Fan Specs - F120Q (CV) Static Pressure

1.05 mmH2O

Fan Specs - F140Q (CV) Static Pressure

1.4 mmH2O

General Rear-Connecting Motherboard Support (BTF, Project Zero)

Yes (ATX)
