RGB

RGB

Typ

AIO

Material

Aluminum

Pumphastighet

800 - 2,800 ± 300RPM

Övriga specifikationer

Fan Life

60,000 hours / 6 Years

Fan Model

F120 RGB Core Fans

Fan Noise

33.88 dBA

Fan Speed

500-1,800 ± 180 RPM

Pump Power

12V DC, 0.3A

Fan Bearing

Fluid Dynamic Bearing

General EAN

5056547202655 (White) / 5056547202662 (Black)

General UPC

810074842730 (White) / 810074842747 (Black)

Tube Length

400mm

Cap Material

Aluminum and plastic

Fan Air Flow

78.86 CFM

Fan Quantity

2

Fan Connector

4-pin PWM

Fan Dimension

120 x 120 x 26mm

Tube Material

Ultra-low Evaporation Rubber with Nylon Braided Sleeve

Fan Air Pressure

2.57 mm H2O

General Warranty

6 years

Radiator Dimensions

123 x 275 x 30mm

General Model Number

RL-KR240-W1 (White) / RL-KR240-B1 (Black)

Water Block Material

Block: Copper Housing: Plastic

Fan Power Consumption

12V DC, 0.2 A, 2.4W

RGB Controller Weight

52.8g

Cap Display Brightness

300 cd/m²

Cap Display Panel Type

Transmissive TFT, 262K color

Cap Display Resolution

240 x 240 px

Water Block Dimensions

Diameter: 74.7mm H: 55.97mm

Cap Display Orientation

Software adjustable Default, +90, +180, and -90 Degrees

RGB Controller Mounting

Magnet and 3M Dual Lock

RGB Controller Dimensions

63.2 x 53.2 x 12.8mm

Compatible Socket & CPU AMD

AMD Socket AM5, AM4, sTRX4*, TR4* (*Threadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper

Cap Display Panel Active Area

1.54" (39.1mm)

Compatible Socket & CPU Intel

Intel Socket LGA 1851/1700, 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron

RGB Controller Input Connector

12V DC / 2.6A

RGB Controller Connection Cables

1x USB 2.0 internal connector 1x SATA power cable

RGB Controller RGB Lighting Channels

3

RGB Controller Output Channel Voltage

5V DC

RGB Controller NZXT RGB Channel Output LED Qty.

Up to 40 LEDs per channel and up to 120 LEDs combined total for the total 3 channels
