WiFi

WiFi 6E

Chipset

Intel Z890

M.2-platser

9120

Ethernet

2.5 Gigabit

PCIe-platser

1x PCIe 5.0 x16 slot (PCIEX16_1), 2x PCIe 4.0 x16 slots (PCIEX16_2 & PCIEX16_3)

SATA-portar

4

Formfaktor

ATX

Minnestyp

DDR5

Minnesplatser

4

Displayutgångar

1x HDMI, 2x Thunderbolt 4

Övriga specifikationer

CPU CPU

Intel Socket LGA 1851 for Intel Core Ultra Processors (Series 2)

Audio Audio

Realtek ALC1220 Audio Codec

General EAN

5056547206202 (White) / 5056547206219 (Black)

General UPC

810074846264 (White) / 810074846271 (Black)

General Warranty

3 years

Wireless Bluetooth

v5.3

General Model Number

N7-Z89XT-W1 (White) / N7-Z89XT-B1 (Black)

Rear I/O Audio jacks

2

Internal I/O Post LEDs

1

General Operating System

Windows 11/10 64-bit

Rear I/O LAN (RJ45) port

1

Internal I/O Power button

1

Internal I/O Reset button

1

Memory Memory Architecture

Dual-Channel

Rear I/O Clear CMOS button

1

Internal I/O USB 2.0 header

2 (Up to 4 USB 2.0 ports)

Rear I/O USB 3.2 Gen 2 ports

4

Internal I/O USB 3.2 Gen1 header

2 (Up to 4 USB 3.2 Gen 1 ports)

Rear I/O Optical S/PDIF out port

1

Expansion Slots M.2 Socket (Key E)

1 (Type 2230 Wi-Fi/BT PCIe Wi-Fi module and Intel CNVio/CNVio2)

Internal I/O 5V ARGB LED connectors

2

Internal I/O NZXT RGB LED connector

1

Internal I/O 4-pin CPU_FAN connector

1

Internal I/O 4-pin AIO_PUMP connector

1

Internal I/O 4-pin SYS_FAN connectors

3

Rear I/O USB 3.2 Gen 1 Type-A® ports

3

Internal I/O NZXT 8-pin PWM connectors

2

Rear I/O USB 3.2 Gen 2x2 Type-C® port

1

Internal I/O 24-pin ATX power connector

1

Internal I/O Front panel audio connector

1

Rear I/O Wireless antenna SMA connectors

2

Internal I/O 8-pin ATX 12V power connector

2

Internal I/O USB 3.2 Gen2x2 front panel header

1 (For USB Type-C)

Memory Intel® Extreme Memory Profile (XMP) 3.0

Supported
