Vikt

8.63 kg

Front I/O

1x USB 3.0 1x USB-C 3.0 Gen2 Microphone, Headphone Combo Reset button Power button + LED

Chassityp

Mid Tower

Material

Steel chassis, Tempered glass

Dimensioner

495 × 230 × 522 mm

Formfaktor

E-ATX, ATX, Micro-ATX, Mini-ITX

Max 120 mm-fläktar

7

Max 140 mm-fläktar

6

2.5"-fack

2

3.5"-fack

2

Medföljande fläktar

Front: 3x 140, Rear: 1x 140

Max GPU-längd

415 mm

Max PSU-längd

270 mm

Sidopanel

Tempered Glass

Expansionsplatser

7

Max kylarhöjd

184 mm

Radiatorstöd (topp)

360 / 280 mm

Övriga specifikationer

Extra Screws

18x Mainboard | SSD screws 4x Power supply screws 8x HDD screws 12x 30 mm fan screws 1x Mainboard stand-off 1x Stand-off removal tool 1x Extra R-side panel screw

Extra Warranty

5 Years limited | Learn more

General UPC Code

886523303558

General Model No.

PH-EC400GA_DBK01

Extra Gross Weight

10.50 kg | 23.14 lbs

Fans 120 | 140 Top

3x | 2x

Extra Accessory Box

30x Zip ties 4x Screw cover corner L 4x Screw cover corner R 4x Screw cover bridge

Fans 120 | 140 Side

- | -

Fans 120 | 140 Bottom

3x | -

Clearance Top Radiator

Length x Width x Height | 360 Radiator | 415 x 138 x 60 mm | 16.33 x 5.43 x 2.36 in | 280 Radiator | 360 x 147 x 65 mm | 14.17 x 5.78 x 2.55 in

Clearance Rear Radiator

Length x Width | 170 x 132 mm | 6.69 x 5.19 in

Extra Scope of Delivery

1x Eclipse G400A chassis 4x M25G2-140 fans (Pre-installed) 1x D-RGB mainboard adapter

Radiators 120 | 140 Rear

120 | -

Radiators 120 | 140 Bottom

- | -

General Vertical GPU Support

3-slots | Riser Cable sold separately

General Rear ATX Mainboard Support

MSI Project Zero | ASUS BTF | Gigabyte Project Stealth
