Djup

235 mm

Bredd

535 mm

Höjd

550 mm

Volym

69.1 L

Vikt

11 kg

Front I/O

1x USB-C 3.2 Gen 2 2x USB 3.0 Microphone, Headphone Reset Button Power Button

Chassityp

Full Tower

Material

Steel chassis, Tempered Glass

Dimensioner

235 × 535 × 550 mm

Formfaktor

SSI-EEB, E-ATX, ATX, Micro-ATX, Mini-ITX

2.5"-fack

4

3.5"-fack

6

Medföljande fläktar

Front: 2x (1x), Rear: 1x (1x)

Max GPU-längd

472 mm

Max PSU-längd

318 mm

Sidopanel

Tempered Glass

Expansionsplatser

8

Max kylarhöjd

185 mm

Radiatorstöd (topp)

420 / 360 mm

Radiatorstöd (front)

240 / 140 mm

Övriga specifikationer

Extra Screws

23x Mainboard | SSD screws 5x Power supply screws 8x HDD locking screws 10x Bracket screws 12x Fan screws 8x Case screws 2x Motherboard stand-off 3x Riser cable screws 12x HDD CM6 #11 8x Reservoir screws 3x Reservoir bracket screws 2x Hook-n-Loop screws 5x Pump bracket upgrade screws

Extra Warranty

5 Years limited | Learn more

General UPC Code

8865233001288

General Model No.

PH-ES614PTG_BK

Extra Gross Weight

15 kg | 33.10 lbs

Extra Accessory Box

10x Zipties Hook-n-loop 1x | 188 x 10 x 1.8 mm 1x | 110 x 10 x 1.8 mm

Clearance Top Radiator

Height | 65 mm | 2.55 in to mainboard

Clearance Side Radiator

Length x Width | -

Extra Scope of Delivery

1x Enthoo Pro chassis 2x SSD bracket 2x 120 mm fans

Clearance Front Radiator

Length x Width | -

Fans 120 | 140 | 200 Top

3x | 3x | 1x

Radiators 120 | 140 Rear

120 | -

Radiators 120 | 140 Side

- | -

Clearance Bottom Radiator

Length x Width | -

Fans 120 | 140 | 200 Side

- | - | -

Radiators 120 | 140 Bottom

Max. 240 | 140

Fans 120 | 140 | 200 Bottom

2x | 1x | -

General Vertical GPU Support

3-slots | Riser Cable sold separately

Fans 120 | 140 | 200 Total Fans

10x | 7x | 2x

General Internal 5.25” ODD Bays

3
