Vikt

14.2 kg

Front I/O

2x USB 3.0 1x USB-C 3.2 Gen2x2 1x Microphone, Headphone combo Power button Reset button

Chassityp

Mid Tower

Material

Steel chassis, Aluminium panels, Tempered glass window, ABS plastic, Polyester

Dimensioner

454 × 228 × 588 mm

Formfaktor

E-ATX, ATX, Micro-ATX, Mini-ITX

Max 120 mm-fläktar

7

Max 140 mm-fläktar

0

2.5"-fack

5

3.5"-fack

2

Max GPU-längd

380 mm

Max PSU-längd

250 mm

Sidopanel

Tempered Glass

Expansionsplatser

8

Max kylarhöjd

170 mm

Övriga specifikationer

Extra Screws

6x Zip ties 1x Stand-off removal tool 1x D-RGB mainboard adapter 500 mm 1x Microfiber cloth

General Color

Brushed aluminium

Extra Warranty

5 Years limited | Learn more

General UPC Code

886523304074

General Model No.

PH-ES524XM_DMW01

Extra Gross Weight

16.5 kg | 36.4 lbs

Fans 120 | 140 Top

3 | -

Extra Accessory Box

30x Mainboard | SSD screws 4x Power supply screws 8x HDD screws 4x Vertical-GPU bracket screws 1x Mainboard stand-off

Fans 120 | 140 Rear

1 | -

Fans 120 | 140 Side

- | -

Fans 120 | 140 Front

- | -

Fans 120 | 140 Bottom

3 | -

Radiator 120 | 140 Top

Max. 360 | -

Extra Scope of Delivery

1x Evolv X2 chassis 1x Storage bracket Pre-installed 1x SSD bracket Pre-installed

Radiator 120 | 140 Rear

- | -

Radiator 120 | 140 Front

- | -

Matrix Display Connectors

Mainboard USB 2.0 header 500 mm SATA 500 mm

Matrix Display LED Amount

900

Radiator 120 | 140 Bottom

- | -

Clearance Top 360 Radiator

Length x Width x Height | 415 x 130 x 32 mm | 16.34 x 5.12 x 1.25 in

Matrix Display Power Input

5V | 5.3A

General Vertical GPU Support

Yes | Riser cable sold separately

Matrix Display Fabric Material

Polyester

General Rear ATX Mainboard Support

MSI Project Zero | ASUS BTF | Gigabyte Project Stealth
