Djup

575 mm

Bredd

280 mm

Höjd

615 mm

Volym

99 L

Vikt

19.52 kg

Front I/O

1x USB 3.2 USB-C Gen2 2x USB 3.0 Microphone, Headphone Combo Power Button D-RGB Mode Button D-RGB Color Button D-RGB Speed Button D-RGB Channel Button

Chassityp

Full Tower

Material

Steel chassis, Tempered glass

Dimensioner

575 × 280 × 615 mm

Formfaktor

E-ATX, ATX, Micro-ATX, Mini-ITX

Max 120 mm-fläktar

12

Max 140 mm-fläktar

11

2.5"-fack

6

3.5"-fack

3

Max GPU-längd

490 mm

Max PSU-längd

210 mm

Sidopanel

Tempered Glass

Expansionsplatser

8

Max kylarhöjd

205 mm

Radiatorstöd (topp)

420 / 360 mm

Övriga specifikationer

Extra Screws

34x Mainboard | SSD screws 4x Power supply screws 4x Thumb screws 9x HDD screws 1x Motherboard stand-off 1x Stand-off removal tool 1x Extra R-side panel screw

Extra Warranty

5 Years limited | Learn more

General UPC Code

886523303084

General Model No.

PH-NV923TG_DMW01

Extra Gross Weight

23.00 kg | 50.70 lbs

Fans 120 | 140 Top

3x | 3x

Extra Accessory Box

2x Airflow covers 1x Microfiber cloth 6x Zip ties 1x GPU support bracket

Fans 120 | 140 Rear

2x | 2x

Fans 120 | 140 Side

4x | 3x

Fans 120 | 140 Front

- | -

Fans 120 | 140 Bottom

3x | 3x

Clearance Top Radiator

Length x Width | 515 x 154 mm | 20.27 x 6.06 in

Clearance Rear Radiator

Length x Width | 325 x 154 mm | 12.79 x 6.06 in

Clearance Side Radiator

Length x Width | 525 x 154 mm | 20.66 x 6.06 in

Extra Scope of Delivery

1x NV9 chassis

Clearance Front Radiator

Length x Width | - | -

Radiators 120 | 140 Rear

Max. 240 | 280

Radiators 120 | 140 Side

Max. 480 | 420

Radiators 120 | 140 Bottom

Max. 360 | 420

General Vertical GPU Support

3-slots | Riser Cable sold separately
